2467-20 M12 angle impact driver

The 2467-20 is a cordless electric angle impact driver manufactured by Milwaukee.

It has a brushed electric motor powered by a 12 volt battery.

Although its maximum torque is significantly below what other 12 volt impact drivers can deliver the shape of the body makes it possible to use this specialized tool in situations that may be impossible for other impact drivers.

Exterior

The machine has a cylindrical shaped plastic red body with black rubberized top and part of the sides. The whole body is also the handle.

An M12 battery is inserted in the back of the body. On the bottom side there is a black variable speed paddle switch that is large enough so that it can be reached with the hand both on the front and back of the body.

Right above the paddle switch is a recessed push button to reverse the turning direction.

On the side of the body, near the top there are four LEDs that act as a battery charge indicator. Milwaukee calls this the "fuel gauge".

On the bottom near the front of the housing is an LED light above it that illuminates the working area.

At the front there is a aluminium gear housing black 1/4" hex bit holder pointing downwards.

Operation

The machine is activated by pushing the black variable speed paddle switch. The turning direction can be reversed with the button above it.

The bit can be removed by pulling the sleeve around the bit holder forward.

Variants

• 2467-21 with charger and battery
